Quality System Process
Quality Inspection Area
Measuring and Quality Capability
- NIKON-LK INTEGRA Coordinate Measuring Machine(CMM)
- Range: 1.5X0.7X0.6 m
- Accuracy: (1.8+L)/350 mm Where “L” Stands for “Part Length”
- Resolution: 0.1 Microns
- Spiral EHL has capability of precision inspection up to 5 Microns
TRIMASTER Height Master
- Range: 0-590mm
- Least Count: 0.001 mm
MITUTOYO PJ-A3000 Profile Projector
- Range: 100 x 100 mm
- Least Count: 0.001 mm
MITUTOYO Height Master
- Range: 0-300mm
- Least Count: 0.01mm
Equipped with all other basic precision measuring Instruments like: Pin Gauges, Slip Gauges, Comparator, Thread plug gauges(TPG) , Plain plug gauges (PPG).
